Ditch Witch Vibratory Ploughs

If your project requires pipe or cable to be installed underground in a quick and cost effective manner, then the vibratory ploughing method is the answer.

Vibratory ploughs are ideal for installing pipe and cable underground in rural/open areas.  MSW Plant Hire has various cable and pull blades available or we can customise an installation blade to meet your requirements.

VibratoryPlough-01VibratoryPlough-02VibratoryPlough-04 SPECIFICATIONS
Horsepower: 95
Steering: 4 wheel steer
Drive Train: 4 wheel drive with diff locks
Machine Weight: 7000kgs
Machine Length: 7300mm
Machine Width: 2100mm
Machine Height: 2850mm
Trencg Depth: Up to 1200mm
Trench Widths: 150mm
Attachments: Side mounted trenching attachment, various cable and pipe pulling blades to suit requirements up to a depth of 850mm, front back-filling blade, reel carrier

VibratoryPlough-specs

The Benefits of Cable/Pipe Vibratory Ploughing

  • No trench is required; this machine will place the cable/pipe underground in one pass with minimal disturbance to the ground.
  • It is perfect for laying cable/pipe underneath sporting areas such as golf courses and racecourses as only an entrance and exit hole is required.
  • As no trench is required, there is no subsiding of the soil and no excess material.
