Ditch Witch Trench Diggers - 115hp Range

Ditch Witch 115hp trench diggers are compact machines, with trenching capabilities from 170mm to 600mm wide and down to 1.5 meters deep.

Our 115hp trencher comes equipped with four wheel steer and side shift attachment. The 115hp trench digger is a versatile machine for your next major trenching project.

TrenchDigger 115hp-02TrenchDigger 40hp-03 SPECIFICATIONS
Horsepower: 115
Steering: 4 wheel steer
Tilt: 7 degrees to the left or right of centre of machine
Drive Train: 4 wheel drive with diff locks
Machine Weight: 7000kgs
Machine Length: 7300mm
Machine Width: 2100mm
Machine Height: 2800mm
Trench Depth: Up to 1500mm
Trench Widths: 170mm, 200mm, 250mm, 300mm, 350mm, 400mm, 450mm, 500mm, 600mm
Attachments: Side shift trenching, attachment with front back-filling blade.
Spoil placement Distributed evenly on both sides

TrenchDigger 115hp-Specs

The Benefits of Trenching

  • A trencher digs 3 to 4 times faster than an excavator/backhoe with less mess.
  • Various size trench widths means you don't have to excavate any more than is required.
  • The spoil is excavated more finely with a trencher so the trench can be easily back-filled with better compaction.
  • As the spoil is much finer it can be suitable for the bedding of pipes and cables, etc.
